Bipost ( Graflex )
Tip # 13 ( on Paramount Cords tip chart )
Bipost ( Graflex )
Fits older Speed Graphic cameras, Crown Graphic,
Wollensak Lenses,
Rodenstock Lenses, Camerez and Photo Control
cameras. Identified by two pin contacts
protruding from the lens about 1/2 inches apart.
Tip #13


Bipost Page
CLICK HERE
*Of course we
can make a Bipost cord with any combination of
tips or plugs to fit any flash, Coiled or
staight, any length go to
Custom Cords Page ( and pick tip # 13
)
Graflex
Solenoid
Tip #
40
( on
Paramount Cords tip chart )

Tip # 40
Only
available as a custom made cord
Go to Custom Cords and choose tip # 40-
CLICK HERE
ASA Bayonette
( Tip # 31 )
(
on Paramount Cords tip chart )
 |
The ASA
Bayonette connector is a small post,
spring loaded at the tip. It has 2 small
protruding nubs. One on each side of the
post. To connect this to the camera you
must push down and turn. This connector
is not common but can be found on old
Kodak cameras as well as some Graflex
lenses. |

Tip # 31 ASA Bayonette
is
Only
available as a custom made cord
Go to Custom Cords -
CLICK HERE ( and choose tip # 31 )
Sync cord page from the
Graflex Catalog ( back when )
Super Speed Graphic - Graflex

Super Speed Graphic tip # SSG-X ** $ 30.00
Refer to tip # SSG-X when ordering. (X sync for
electronic flash)
The Super Speed Graphic has 3 contact
female connector. The two pins widest apart are
X sync.( electronic flash ).
The 2 pins closest together are used for M sync
( bulb).
This cord is only available as a custom made
cord. See
Custom Cord page.
**( Other components must be added to create
this custom cord)
Graflex Tripost ( very rare )
Graflex 1000 shutter, Graflex Optar 135mm,
Rodenstock
Contains both X and M sync
Uses our standard Bipost tip number 13
(Photo courtacy of Joaquin, Santa Monica, Ca)
Graflex Flash Plug
Fits into Graflex flashgun handle.
This tip must be ordered by phone.
$35.00 for this tip when added to other tips in
a custom cord

|
